Steel Module

The Scalypso Steel Module allows to reconstruct and export steel beam geometries in real-time to your CAD system.  Thereby, you are supported by our built-in library, which offers a wide range of DIN and EN norm steel beams. Other beam geometries can be easily added using an integrated editor.

With the definition of just a few points in the scan our steel module would open and suggests you a list of steel beams which possibly would fit. For often used items, you are also able to create a favorites list to speed-up the selection.

Features

  • Steel beam reconstruction and export
  • Measurement of surface flatness
  • Real-time export interface to different CAD systems
  • Library with  more than 2000 common steel beams (DIN and EN norm)
  • Editor for defining own steel beam geometries
  • Tools for visual inspection and correction of reconstructed steel beams
